Motor Control Units
Electrifies traction and supplementary applications with
6-phase and 3-phase motors
400V Dual-Inverter
Available output power ratings
2x 180 kVA peak / 2x 90 kVA cont.
2x 100 kVA peak / 2x 50 kVA cont.
Technical specs
Output current
2x 450 Arms peak / 2x 240 Arms cont.
2x 260 Arms peak / 2x 130 Arms cont.
Input voltage range 190-450 V
Efficiency 98%
Liquid cooling
Dimensions 368*342*157.2 mm; 20 L; 16 kg
Dual inverter for full hybrid application
400V Dual Inverter for Hybrid
Available output power ratings
TM 180 kVA peak / 90 kVA cont.
GM 140 kVA peak / 65 kVA cont.
TM - Traction Motor, GM - Generation Motor
Technical specs
Output current
TM 510 Arms peak / 240 Arms cont.
GM 350 Arms peak / 166 Arms cont.
Input voltage range 210-450 V
Efficiency 99%
Liquid cooling
Dimensions 422*222*136 mm; 7,4L; 10,3 kg
Electrifies traction and supplementary applications with
3-phase motors
400V Single Inverter
Available output power ratings
180 kVA peak / 90 kVA cont.
100 kVA peak / 50 kVA cont.
Technical specs
Output current
450 Arms peak / 240 Arms cont.
260 Arms peak / 130 Arms cont.
Input voltage range 190-450 V
Efficiency 98%
Liquid cooling
Dimensions 301.5*297*99 mm; 8,9 L; 10 kg
Electrifies traction and supplementary applications with
3-phase motors
800V Inverter for Heavy Duty
Available output power ratings
700 kVA peak / 470 kVA cont
Technical specs
Output current
900 Arms peak / 600 Arms cont.
Input voltage range 660 - 850 V
Efficiency 98%
Liquid cooling
Dimensions 430*395.6*139.5 mm; 25.45 kg
Electrifies traction and supplementary applications with
3-phase motors
800V Single Inverter
Available output power ratings
200 kVA peak / 135 kVA cont.
Technical specs
Output current
300 Arms peak / 200 Arms cont.
Input voltage range 260 - 850 V
Efficiency 98%
Liquid cooling
Dimensions 301.5*297*97,5 mm; 8,73 L; 8 kg
